In this section, we'll explain what XML external entity injection is, describe some common examples, explain how to find and exploit various kinds of XXE injection, and summarize how to prevent XXE injection attacks.

What is XML external entity injection?

XML external entity injection (also known as XXE) is a web security vulnerability that allows an attacker to interfere with an application's processing of XML data. It often allows an attacker to view files on the application server filesystem, and to interact with any back-end or external systems that the application itself can access.

In some situations, an attacker can escalate an XXE attack to compromise the underlying server or other back-end infrastructure, by leveraging the XXE vulnerability to perform server-side request forgery (SSRF) attacks.

How do XXE vulnerabilities arise?

Some applications use the XML format to transmit data between the browser and the server. Applications that do this virtually always use a standard library or platform API to process the XML data on the server. XXE vulnerabilities arise because the XML specification contains various potentially dangerous features, and standard parsers support these features even if they are not normally used by the application.

XML external entities are a type of custom XML entity whose defined values are loaded from outside of the DTD in which they are declared. External entities are particularly interesting from a security perspective because they allow an entity to be defined based on the contents of a file path or URL.

What are the types of XXE attacks?

There are various types of XXE attacks:

• Exploiting XXE to retrieve files, where an external entity is defined containing the contents of a file, and returned in the application's response.
• Exploiting XXE to perform SSRF attacks, where an external entity is defined based on a URL to a back-end system.
• Exploiting blind XXE exfiltrate data out-of-band, where sensitive data is transmitted from the application server to a system that the attacker controls.
• Exploiting blind XXE to retrieve data via error messages, where the attacker can trigger a parsing error message containing sensitive data.

Exploiting XXE to retrieve files

To perform an XXE injection attack that retrieves an arbitrary file from the server's filesystem, you need to modify the submitted XML in two ways:

• Introduce (or edit) a DOCTYPE element that defines an external entity containing the path to the file.
• Edit a data value in the XML that is returned in the application's response, to make use of the defined external entity.

For example, suppose a shopping application checks for the stock level of a product by submitting the following XML to the server:

<?xml version='1.0' encoding='UTF-8'?>
<stockCheck><productId>381</productId></stockCheck>

The application performs no particular defenses against XXE attacks, so you can exploit the XXE vulnerability to retrieve the /etc/passwd file by submitting the following XXE payload:

<?xml version='1.0' encoding='UTF-8'?>
<!DOCTYPE foo [ <!ENTITY xxe SYSTEM 'file:///etc/passwd'> ]>
<stockCheck><productId>&xxe;</productId></stockCheck>

This XXE payload defines an external entity &xxe; whose value is the contents of the /etc/passwd file and uses the entity within the productId value. This causes the application's response to include the contents of the file:

Invalid product ID: root:x:0:0:root:/root:/bin/bash
daemon:x:1:1:daemon:/usr/sbin:/usr/sbin/nologin
bin:x:2:2:bin:/bin:/usr/sbin/nologin
...

Note

With real-world XXE vulnerabilities, there will often be a large number of data values within the submitted XML, any one of which might be used within the application's response. To test systematically for XXE vulnerabilities, you will generally need to test each data node in the XML individually, by making use of your defined entity and seeing whether it appears within the response.

Exploiting XXE to perform SSRF attacks

Aside from retrieval of sensitive data, the other main impact of XXE attacks is that they can be used to perform server-side request forgery (SSRF). This is a potentially serious vulnerability in which the server-side application can be induced to make HTTP requests to any URL that the server can access.

To exploit an XXE vulnerability to perform an SSRF attack, you need to define an external XML entity using the URL that you want to target, and use the defined entity within a data value. If you can use the defined entity within a data value that is returned in the application's response, then you will be able to view the response from the URL within the application's response, and so gain two-way interaction with the back-end system. If not, then you will only be able to perform blind SSRF attacks (which can still have critical consequences).

In the following XXE example, the external entity will cause the server to make a back-end HTTP request to an internal system within the organization's infrastructure:

<!DOCTYPE foo [ <!ENTITY xxe SYSTEM 'http://internal.vulnerable-website.com/'> ]>

Blind XXE vulnerabilities

Many instances of XXE vulnerabilities are blind. This means that the application does not return the values of any defined external entities in its responses, and so direct retrieval of server-side files is not possible.

Blind XXE vulnerabilities can still be detected and exploited, but more advanced techniques are required. You can sometimes use out-of-band techniques to find vulnerabilities and exploit them to exfiltrate data. And you can sometimes trigger XML parsing errors that lead to disclosure of sensitive data within error messages.

Finding hidden attack surface for XXE injection

Attack surface for XXE injection vulnerabilities is obvious in many cases, because the application's normal HTTP traffic includes requests that contain data in XML format. In other cases, the attack surface is less visible. However, if you look in the right places, you will find XXE attack surface in requests that do not contain any XML.

XInclude attacks

Some applications receive client-submitted data, embed it on the server-side into an XML document, and then parse the document. An example of this occurs when client-submitted data is placed into a back-end SOAP request, which is then processed by the backend SOAP service.

In this situation, you cannot carry out a classic XXE attack, because you don't control the entire XML document and so cannot define or modify a DOCTYPE element. However, you might be able to use XInclude instead. XInclude is a part of the XML specification that allows an XML document to be built from sub-documents. You can place an XInclude attack within any data value in an XML document, so the attack can be performed in situations where you only control a single item of data that is placed into a server-side XML document.

To perform an XInclude attack, you need to reference the XInclude namespace and provide the path to the file that you wish to include. For example:

<foo xmlns:xi='http://www.w3.org/2001/XInclude'>
<xi:include parse='text' href='file:///etc/passwd'/></foo>

XXE attacks via file upload

Some applications allow users to upload files which are then processed server-side. Some common file formats use XML or contain XML subcomponents. Examples of XML-based formats are office document formats like DOCX and image formats like SVG.

Blind Xxe Cheat Sheet

For example, an application might allow users to upload images, and process or validate these on the server after they are uploaded. Even if the application expects to receive a format like PNG or JPEG, the image processing library that is being used might support SVG images. Since the SVG format uses XML, an attacker can submit a malicious SVG image and so reach hidden attack surface for XXE vulnerabilities.

XXE attacks via modified content type

Most POST requests use a default content type that is generated by HTML forms, such as application/x-www-form-urlencoded. Some web sites expect to receive requests in this format but will tolerate other content types, including XML.

For example, if a normal request contains the following:

POST /action HTTP/1.0
Content-Type: application/x-www-form-urlencoded
Content-Length: 7
foo=bar

Then you might be able submit the following request, with the same result:

POST /action HTTP/1.0
Content-Type: text/xml
Content-Length: 52
<?xml version='1.0' encoding='UTF-8'?><foo>bar</foo>

If the application tolerates requests containing XML in the message body, and parses the body content as XML, then you can reach the hidden XXE attack surface simply by reformatting requests to use the XML format.

How to find and test for XXE vulnerabilities

The vast majority of XXE vulnerabilities can be found quickly and reliably using Burp Suite's web vulnerability scanner.

Manually testing for XXE vulnerabilities generally involves:

• Testing for file retrieval by defining an external entity based on a well-known operating system file and using that entity in data that is returned in the application's response.
• Testing for blind XXE vulnerabilities by defining an external entity based on a URL to a system that you control, and monitoring for interactions with that system. Burp Collaborator client is perfect for this purpose.
• Testing for vulnerable inclusion of user-supplied non-XML data within a server-side XML document by using an XInclude attack to try to retrieve a well-known operating system file.

How to prevent XXE vulnerabilities

Virtually all XXE vulnerabilities arise because the application's XML parsing library supports potentially dangerous XML features that the application does not need or intend to use. The easiest and most effective way to prevent XXE attacks is to disable those features.

Generally, it is sufficient to disable resolution of external entities and disable support for XInclude. This can usually be done via configuration options or by programmatically overriding default behavior. Consult the documentation for your XML parsing library or API for details about how to disable unnecessary capabilities.

Xxe Cheat Sheet 2020

Ask questionsUpdate: XML External Entity (XXE) Prevention Cheat Sheet

The JAXB > Java 8 and Up sub-section on the XXE Cheat Sheet can be misleading. The advice in this section succinctly states

Since JDK-8010393, which is in OpenJDK 8 beta 86, javax.xml.bind.Unmarshaller instances are safe by default. The other classes mentioned here are still unsafe by default in Java 8.

Xxe Dtd

This statement is too broad. It does not account for all the nuances that can lead the javax.xml.bind.Unmarshaller to be vulnerable or used in a way that is vulnerable on OpenJDK 1.8 based runtimes. An application parsing untrusted XML on an OpenJDK 1.8 runtime may be vulnerable to XXE if

• the JAXB runtime has been inadvertently replaced with a different JAXB runtime that is not safe-by-default (e.g. EclipseLink MOXy)
• the secure SAX parser that the OpenJDK 1.8 Unmarshaller uses has been inadvertently replaced with a different implementation that is not safe-by-default (e.g. xercesImpl:2.8.0)
• the application uses one of the unmarshal overloads that does not delegate XML parsing to the safe-by-default SAX parser

Elaborating on that last point, even if the Unmarshaller is considered safe by default, not all of its unmarshal methods use the safe by default XMLReader. Calling unmarshal with any of the following argument types still requires the user to explicitly configure the XML parsing to be safe

• javax.xml.transform.stream.SAXSource
• org.w3c.dom.Node
• javax.xml.stream.XMLStreamReader
• javax.xml.stream.XMLEventReader

The following is a detailed analysis that explains why users should not rely on the safe by default nature of the Unmarshaller in OpenJDK 1.8 https://www.contrastsecurity.com/security-influencers/xml-xxe-pitfalls-with-jaxb

Recommend removing this sub-section from the Cheat Sheet
